D-link Cat 6 Cable Copper outdoor UTP 23 AWG
Availability:In Stock!
D-link Cat 6 Cable Copper outdoor UTP 23 AWG
D-Link Ethernet Cables provide an easier and cost-effective way to create a Local Area Network that supports Gigabit Ethernet (1000Base-T) standard. The Ethernet Cables are designed to operate at a bandwidth of up to 250 Mhz.
KSh19,200.00 Excl. VAT
CompareDescription
D-link Cat 6 Cable Copper outdoor
UTP 23 AWG
Specifications and technical details
- Category 6 UTP Solid cable Color: Cool Gray 10C
- Model- Brand : D Link : NCB-C6UGRYR-305
- Full box cable Length type: 305M ( 1000ft)
- Specific Heat-resistant: 75ohm
- Cat 6 D-link cable Conductor : 23 AWG(0.574 / 0.007mm) Bare Copper
- Insulation Material: HD-PE
Technical Details
Capacitance : 5.6nF/100m nominal
Impedance : 100Ω/15%,1-600MHz
Nominal Velocity of Propagation: 69%
Operating Temperature : -20℃-60℃(-4℉-140℉)
Storage Temperature : -20℃-80℃(-4℉-176℉) “
Certifications
“Certified for UL 444 (for Copper conductor)
UL 758/ Style 2835 (for Copper, CCA, CCAM & CCS conductors)
UL 1581 (Test standard)
TIA/EIA-568B.2 (Test standard).
FCC Part 68.500 or IEC 60603-7-4 (for Modular connector)
Application
Structured Cabling infrastructure, Gigabit, and fast
speeds and “10BASE-T, 100BASE-TX Fast Ethernet, 1000BASE-T, 10GBASE-T (IEEE802.3)
100VG-AnyLAN (IEEE802.12)
550 MHz Broadband Video
Voice, T1, ISDN Cabling
155/ 622 Mbps ATM
For Power over Ethernet (POE)
- 4 Pairs Unshielded Twisted Pair (UTP) Cable
- Conductor Metal: Solid Bare Copper with 23 AWG
- Color Code: Gray
- Jacket Material: PVC UL94V-0
- PE Central Cross separator
- Mutual Capacitance: 5.6nF/100m nominal
- Characteristic Impedance: 100Ω±15%
- Nominal Velocity of Propagation: 69%
- Conductor Resistance: < 9.38Ω/100m
- Mutual Capacitance: < 5.6nF/100m
- Resistance Unbalance: 5% Max
- Capacitance Unbalance: 330pF/100m
- Delay Skew: < 45nS
- Conductor Diameter : 0.560mm Nominal
- Insulation Diameter: 0.97mm Nominal
- Insulation Material: HD-PE
- Cable Diameter: 6.0mm
